Computerized Register Rotogravure Printing Press DNAY800.1100A manufacturer from China Zhejiang Deguang Machinery Co.,Ltd

Computerized Register Rotogravure Printing Press

Payment Terms:	T/T,L/C
Place of Origin:	Zhejiang, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: DNAY800.1100A

Production Capacity: 30sets/month

Plate: Gravure

Color & Page: Multicolor

Means of Transport: Ocean,Land

Delivery Date: 30days

Type: Rotogravure Printing Machin...

Brand Name: Deguang

It is applicable cork paper,cellphane,BOPP,PET,PVC,PE,paper,broadly applied for all types of super-quality printed matters.

We are the manufacturers and suppliers of computerized register rotogravure printing press and specializes in the field for 30 years in China.DNAY800.1100A model rotogravure printing presses are applicable for BOPP,PET,PVC,PE and combined film and paper with the same properties.

1/This model is high speed rotogravure printing press with high precision, high efficiency and less waste;

2/The installation of printing cylinders adopts air cylinder to pull the core of axis to install the cylinders.

3/Plastic film rotogravure printing press adopts dual air cylinder to increase the pressure and solenoid valve to locate the position;
4/Automatic rotogravure printing press adopt computer to control register precision.

5/The unwinding and rewinding of rotogravure printing press adopts dual station and it can change material and rewinding material automatically.The unwinding shelf adopt magnetic powder tension controlling and rewinding shelf adopt torque motor.Less waste and lower cost.

6/The drying system of rotogravure printing press adopts fully-closed oven,outer second dry air resource returning design.It will save energy.

Main Technical Parameters:

1).Printing width;420-1100mm

2).Printing speed:120m/min

3).Printing plate dia:100-350mm

4).Guiding roller width: 830mm or 1130mm.

5).Unwinding and rewinding dia: 600mm

6).Registration precision: Vertical ±0.1mm

7).Drying method: Electric heating or oil heating.

8).Total power: 123KW or 138KW

9).Weight: 12000kg 13000kg

10).Dimension:800 model: 13500×3000×3100mm
